Description
SuperFoil Plus for Cold Foil Applications
SuperFoil Plus is a compressible printing blanket developed for cold foiling applications, suitable for use with all types of inline foiling modules for sheetfed printing presses, such as; Foiltone, Compact Foiling, Foilstar, Eagle Systems.
The rubber surface has a very fine top surface with high rub and scratch resistance.
- Excellent transfer property
- No static electricity
- High rub and scratch resistance
- Long life on press
- Flexible
- 1.95mm thickness
| Technical Data | |
| Colour | Red |
| Construction | 3 fabric layers |
| Compressible layer | Closed cell |
| Nominal thickness | 1.95mm |
| Thickness Ranges | 1.93mm – 1.97mm |
| Roughness (Ra) | 0.5 – 0.7 µm |
| Surface hardness | 67° Shore A |
| Overall hardness | 77° Shore A |
| Tensile strength at break | >80 N/mm |
| Elongation at break | <4.5 % |
| Compressibility | 0.14mm at 1060kPa Typical
0.21mm at 2060kPa Typical |
