Description
Lightweight and robust sleeves for mounting plates glued with adhesive tape
BFS mounters meet all the requirements of the Flexo wide web printer.
Our mounting sleeves provide the combination of high quality and cost-effectiveness that the print market demands.
BFS Advantages:
- Light for easy handling
- Hard Wearing
- Dimensional stability
- Optimal construction methods offer superior strength and stability
- Tight tolerances produce a consistent register
accuracy and print quality - Less movement on print runs
- Conductive and non-conductive versions
| Material | fibreglass sleeve, polyurethane foam, polyurethane 80 Sh D |
| Diameter | from 44 mm to 630 mm |
| Length | up to 3700 mm |
| Wall thickness | according to customer requirements (max. 250 mm) |
| Diameter tolerance | ± 0,02 mm |
| Runout tolerance | TIR ≤ 0,02 mm |
| Air flow | > 12 l/s (0,42 cubic ft/sec.) |
| Pressure | 6 – 8 bar (87 – 116 psi) |
| Line | axial or radial line according to customer requirements |
| Metal notch | shape according to customer requirements |
Please contact our sales office for a free no obligation quotation. Get A Quote
