Description
Aco Otto is an all-round blanket for a wide range of substrates and applications: sheetfed, metal decorating, packaging.
AcoOtto has excellent performance in the commercial sheet fed, packaging and metal decorating sectors; it also works very well for hybrid applications (traditional and UV inks). The compressible layer is made with closed-cell technology and the carcass structure is composed of high quality fabrics, giving it great dimensional stability. AcoOtto has an excellent rebound that limits its loss of thickness and does not require re-tensioning during use.
- Competitively priced, high performing printing blanket
- Conventional and hybrid inks
- Does not require re-tensioning
- Does not lose thickness
- ISEGA certified
Product Information
Colour: Light blue
Construction: 3 fabric layers
Compressible Layer: Closed cells
Nominal Thickness: 1.95mm
Thickness Range: 1.92 ÷ 1.96mm
Roughness Ra: 0.8 micron
Surface Hardness: 60° Shore A
Hardness (total): 77° Shore A
Tensile Strength: >60Kg/cm²
Elongation at Break: <4.5%
Compressibility: 20-35 Kg/cm² at 0.23mm deformation
Application Fields: Sheetfed, metal decorating, packaging
Identification Lines: Red+Green
Ink Compatibility: Resistant to conventional and hybrid inks
