Description
AcoUV Plus is a high quality blanket, ideal for sheet fed, metal decorating, packaging and narrow web printing for excellent printing results with UV inks.
AcoUV Plus is the ideal rubber blanket for high quality printing using UV inks. It can exceed 20,000 impressions/hour. The compressible layer is made with closed cell technology and the carcass structure is composed of high quality fabrics, giving it great dimensional stability and the right resistance for large formats. AcoUV Plus has an excellent rebound that limits its loss of thickness and does not require re-tensioning during use.
- No ghosting
- Does not require re-tensioning
- Does not lose thickness
- ISEGA certified
- EPDM rubber surface resistant to UV inks
- For pure UV printing
Product Information
Colour: Violet
Construction: 3 fabric layers
Compressible Layer: Closed cells
Nominal Thickness: 1.70mm / 1.95mm
Thickness Range: 1.67 ÷ 1.71mm / 1.92 ÷ 1.96mm
Roughness Ra: According to application
Surface Hardness: 60° Shore A
Hardness (total): 77° Shore A
Tensile Strength: >75Kg/cm²
Elongation at Break: <4.5%
Compressibility: 20-35 Kg/cm² at 0.23mm deformation
Application Fields: Large sheetfed size, narrow web, packaging
Identification Lines: Red+Green
Ink Compatibility: Resistant to UV inks
